The Jaguar XK150 was introduced in May 1957 in Fixed Head Coupe and Drophead Coupe form replacing the XK140 range. The Roadster version came along in March 1958. All cars used the XK140 chassis but this time the bodywork was of a much more modern appearance and for the first time featured a one piece curved windscreen. Inside the vehicle the walnut veneer on the dashboard and door cappings had been replaced with padded leather trim. Mechanically one of the main changes to the XK150 were the Dunlop disc brakes which were used both front and rear as opposed to drums which were fitted to the XK140. The engine however was from the 140, and as before was available in standard tune, or in a higher performance version on the Special Equipment models. The Standard model had the 190 bhp of the earlier car but this time for the "SE" or S as it became known, power was up to a heady 250 bhp. This was achieved mainly by a new design of cylinder head (which became known as the straight port cylinder head) and triple two inch S.U. carburettors. Overdrive which had been optional also became standard fitment in 1958. In 1959 a 3.8 litre engine became available with 220 bhp in standard form and 265 bhp in the "S" versions. Production of all models ended in October 1960.
Specifications |
|||
---|---|---|---|
Model |
Roadster |
Drophead Coupe |
Fixed Head Coupe |
Years Produced |
1958-1960 |
1957-1960 |
1957-1960 |
Body Type |
Steel body (alloy bonnet and boot) on separate chassis |
||
Length |
14ft 9in |
14ft 9in |
14ft 9in |
Width |
5ft 4.5in |
5ft 4.5in |
5ft 4.5in |
Engine 3.4 / 3.4S |
6 cylinder twin overhead camshaft 3442cc inline |
||
Engine 3.8 / 3.8S |
6 cylinder twin overhead camshaft 3781cc inline |
||
Power 3.4 / 3.4S |
Standard models - 190 bhp @ 5500 rpm / S - 250 bhp @ 5500 rpm |
||
Power 3.8 / 3.8S |
Standard models - 220 bhp @ 5500 rpm / S - 265 bhp @ 5500 rpm |
||
Gearbox |
4 speed, synchro on 2nd, 3rd and top, optional overdrive or automatic |
||
Driven Wheels |
Rear |
Rear |
Rear |
Brakes |
Servo assisted Dunlop disc brakes front and rear |
||
Front Suspension |
Independent by torsion bar & wishbone, anti-roll bar |
||
Rear Suspension |
Live axle / leaf spring |
Live axle / leaf spring |
Live axle / leaf spring |
Performance 3.4 |
|||
---|---|---|---|
Model |
Roadster |
Drophead Coupe |
Fixed Head Coupe |
Top Speed |
130 mph |
123 mph |
124 mph |
0-60 mph |
7.6 seconds |
8.7 seconds |
8.3 seconds |
Fuel Consumption |
20 mpg |
20 mpg |
20 mpg |
Performance 3.4S |
|||
---|---|---|---|
Model |
Roadster |
Drophead Coupe |
Fixed Head Coupe |
Top Speed |
135 mph |
132 mph |
134 mph |
0-60 mph |
7.3 seconds |
7.4 seconds |
7.6 seconds |
Fuel Consumption |
18 mpg |
17 mpg |
19 mpg |
Performance 3.8 |
|||
---|---|---|---|
Model |
Roadster |
Drophead Coupe |
Fixed Head Coupe |
Top Speed |
134 mph |
129 mph |
130 mph |
0-60 mph |
7.4 seconds |
7.5 seconds |
7.8 seconds |
Fuel Consumption |
18 mpg |
18 mpg |
18 mpg |
Performance 3.8S |
|||
---|---|---|---|
Model |
Roadster |
Drophead Coupe |
Fixed Head Coupe |
Top Speed |
136 mph |
133 mph |
136 mph |
0-60 mph |
7.2 seconds |
7.3 seconds |
7.5 seconds |
Fuel Consumption |
17 mpg |
16 mpg |
17 mpg |
