Jaguar Mk II Saloon

Back to make | On this page: Specifications, Performance Data, Useful Links, Gallery

Jaguar Mk II

The Mk II Jaguar was launched in October 1959 to replace the 2.4 & 3.4 litre saloons, which were immediately to become known as the Mk I. The Mk II was heavily based on its predecessor but had a much lighter and more modern appearance. This was mainly due to a much larger glass area achieved by the use of deeper windows and slimmer window frames that were no longer part of the door mouldings. There were also many detail trim changes, and whilst the interior had undergone a complete redesign, it remained very luxurious with wood veneer and leather in abundance. Mechanically the rear track had been widened and improvements made to the suspension geometry. The 2.4 & 3.4 litre engines were carried forward from the Mk I but had gained slightly more power, and a third engine - the 3.8 litre, was now available. As with the larger engined version of the MK I saloon, the 3.8 litre Mk II had outstanding performance and was for a long time the fastest production saloon car in the world. The Mk II Jaguar was discontinued in 1967 with the introduction of the almost identical 240 & 340 saloon. This time though, there was not to be a 3.8 version, although this engine (along with the 3.4) was still being used in the slightly larger Jaguar S-Type, which featured independent rear suspension.




Specifications

Model

2.4

3.4

3.8

Years Produced

1959-1967

1959-1967

1959-1967

Body Type

4-door saloon, all steel unitary construction

Length

15ft 1in

15ft 1in

15ft 1in

Width

5ft 7in

5ft 7in

5ft 7in

Weight

3192lb

3304lb

3360lb

Engine

6 cylinder 2483cc dohc

6 cylinder 3442cc dohc

6 cylinder 3781cc dohc

Power

120 bhp @ 5750 rpm

210 bhp @ 5500 rpm

220 bhp @ 5500 rpm

Torque

144lb ft @ 2000 rpm

215lb ft @ 3000 rpm

240lb ft @ 3000 rpm

Gearbox

4 speed, synchro on 2nd, 3rd and top, optional overdrive or 3speed auto

Driven Wheels

Rear

Rear

Rear

Brakes

Discs front & rear

Discs front & rear

Discs front & rear

Front Suspension

Independent by coil spring & wishbone, anti-roll bar

Rear Suspension

Trailing link by cantilever semi-elliptic springs, parallel radius arms



Performance

Model

2.4

3.4

3.8

Top Speed

102 mph

120 mph

125 mph

0-60 mph

14.5 seconds

11.5 seconds

8.5 seconds

Fuel Consumption

18 mpg

17 mpg

16 mpg
